2021 Mercedes-Benz AMG GLE-Class, AMG GLS-Class Retrofit Vibration Damper for Exhaust System

TO: Mercedes-Benz Dealer Principals, General Managers, Sales Managers, Service Managers, Parts Managers	FROM: Gregory Gunther, Department Manager, Vehicle Compliance and Analysis, Engineering Services
RE: Service Campaign Launch Notification Retrofit Exhaust System Vibration Damper MY21 167  (AMG GLE-Class, AMG GLS-Class)	DATE:  October 22, 2021



IMPORTANT NEW SERVICE CAMPAIGN LAUNCH INFORMATION



Please note that all customer inquiries should be directed to the Customer Assistance Center at 1-800-FORMERCEDES.



Sincerely,

Gregory Gunther

Department Manager, Vehicle Compliance & Analysis



---

Service Campaign Launch Notification			October 22, 2021
Campaign No. :	Campaign Desc. :		Retrofit Vibration Damper for Exhaust System
2021070013	21P4991005
This is to notify you of the Service Campaign Launch to retrofit the exhaust system vibration damper in 74  Model Year (“MY”) 2021 AMG GLE-Class and AMG GLS-Class (167 platform) vehicles.  The vehicles will be visible and flagged in VMI as “OPEN” on October 22, 2021.
Background
Issue		Mercedes-Benz AG (“MBAG”), the manufacturer of Mercedes-Benz vehicles, has determined that on certain MY 2021 AMG GLE-Class and AMG GLS-Class (167 platform) vehicles, the exhaust system does not correspond to the current production configuration. It is possible that the vibration damper assembly could become damaged due to vibrations while driving.
What We’re Doing		MBUSA will conduct a service campaign.  An authorized Mercedes-Benz dealer will  replace the exhaust system vibration damper assembly.
Parts		The Remedy is available and can be performed as necessary.
Vehicles Affected
Vehicle Model Year(s)		2021
Vehicle Model		GLE-Class, GLS-Class
Vehicle Populations
Total Campaign Population		74
Next Steps/Notes
AOMS/SOMS		AOMs – This campaign may generate questions from your dealers.
While we regret any inconvenience this may cause, MBUSA is determined to maintain a high level of vehicle quality and customer satisfaction. Please refer all customer inquiries to the Customer Assistance Center at 1-800-FOR-MERCEDES.



---



Campaign No. 2021070013, October 2021



TO:	ALL MERCEDES-BENZ CENTERS
SUBJECT:	Model AMG GLE-Class and AMG GLS-Class (167 platform) Model Year 2021 Retrofit Vibration Damper for Exhaust System



Mercedes-Benz AG (“MBAG”), the manufacturer of Mercedes-Benz vehicles, has determined that on certain MY 2021 AMG GLE-Class and AMG GLS-Class (167 platform) vehicles, the exhaust system does not correspond to the current production configuration. It is possible that the vibration damper assembly could become damaged due to vibrations while driving. MBUSA will conduct a service campaign. An authorized Mercedes-Benz dealer will replace the exhaust system vibration damper assembly.



Prior to performing this Campaign:

• VMI must always be checked before performing campaigns to verify that the campaign is required on a specific vehicle. Always check for any other open campaigns, and perform accordingly.
• Please review the entire Campaign bulletin and follow the repair procedure exactly as described.



Approximately 74 vehicles are affected.



Order No. P-SC-2021070013



---

Retrofit Vibration Damper for Exhaust System

Model 167



Work Procedure



1. Replace center exhaust system.

For basic data, see AR49.10-P-7283MNO.



2. Replace bracket (A) with rubber mount on left and right of exhaust system at transmission crossbeam (figures 1 and 2).



3. Retrofit vibration damper.



3.1. Remove bolts (B) from catalytic converter mounting support (Figure 3).

Removed bolts are no longer required!



3.2. Attach new bolts to catalytic converter mounting support.

Part number of new bolts N000000

Do not tighten new bolts (Figure 4)!



3.3. Prepare vibration damper bracket (C) for installation (Figure 5).

3.3.1. Remove nuts (D) and washers (E) from vibration damper bracket (Figure 5).

3.3.2. Remove U- bolt (F) from vibration damper bracket (Figure 5).



3.4. Position vibration damper bracket at catalytic converter exhaust pipe.

The U-shaped vibration damper bracket section must be flush with the catalytic converter exhaust pipe (Figure 6)!

The open-ended elongated holes of the vibration damper bracket must face the same direction as the open-ended elongated holes of the catalytic converter mounting bracket. (Figure 7)!



3.5. Tighten bolts (G) for the vibration damper bracket to the catalytic converter bracket (Figure 8).

Torque: 20 Nm !



3.6. Position U-bolt, washers and nuts of vibration damper.



3.6.1. Attach U-bracket above exhaust pipe on vibration damper.



3.6.2. Attach clamping disks to U-bolt.

Ensure clamping disks are correctly aligned!

The raised side of the washer must point in direction of nut (Figure 9)!



3.6.3. Secure nuts of vibration damper.



3.6.3.1. Attach nuts to vibration damper.

Torque: 5 Nm !



3.6.3.2. The threaded ends of the U-bolt must have the same length/number of threads protruding from the back side of the nuts before torqueing to specification (Figure 10).



4. Assemble lower rear engine compartment lining in reverse order.



Primary Parts Information

Qty.	Part Name	Part Number
2	Bolt (hexalobular M8 X 25)	N 000000 004917
1	Vibration damper	A 167 491 94 00
As required*	Cold-end center piece (V167 without U78)	A 167 490 44 05*
As required*	Cold-end center piece (V167 with U78)	A 167 490 45 05*
As required*	Cold-end center piece (C167 without U78)	A 167 490 46 05*
As required*	Cold-end center piece (C167 with U78)	A 167 490 47 05*
As required*	Cold-end center piece (X167 without U78)	A 167 490 48 05*
As required*	Cold-end center piece (X167 with U78)	A 167 490 49 05*
1	Bracket with rubber mount on left	A 167 491 86 00
1	Bracket with rubber mount on right	A 167 491 87 00



* The replacement parts must be determined according to the equipment variant for the chassis number via the parts job in the Xentry Portal.



Small parts such as screws, lock nuts, sealing rings, cable ties, fluids, sealant, etc. are not listed in the parts list. The required small parts are taken into account in the budgeting.



Note: The following allowable labor operation should be used when submitting a warranty claim for this repair:



Warranty Information

Damage Code	Operation Number	Description	Labor Time (hrs.)
49 910 05	02-1968	Rework exhaust system Includes: Remove/install lower engine compartment lining; remove/install left, right and center rear trim at underbody; replace center exhaust system; replace left and right bracket of exhaust system at transmission crossbeam; retrofit vibration damper	3.6 h
	02-9676	Extra work for: Remove/install engine compartment lining in vehicle with underbody protection	ZM



Note: Always check ASRA for the current OP-Code times. Labor times are subject to change and updates may not be reflected in this document.



---

Retrofit Vibration Damper for Exhaust
Model AMG GLE and GLS-Class vehicles (167 platform)
Model Year 2021
