TO: Mercedes-Benz Dealer Principals, General
Managers, Sales Managers, Service Managers,
Parts Managers
FROM: Anthony Washington, Senior Manager,
Regula􀆟ons and Cer􀆟fica􀆟ons
Re: Launch Recall Campaign No􀆟fica􀆟on
Model: Metris (447)
Model Years: 2022-2023
Replace Fuel Delivery Module
DATE: April, 2024
IMPORTANT RECALL CAMPAIGN INFORMATION
Please see the atached documents related to the campaign listed above.
Campaign No. : Campaign Desc. : Replace Fuel Delivery Module(dealer inventory only)
2024040005 VS2KRAPUM2
This is to no􀆟fy you of a Recall Campaign Launch to replace the fuel delivery module on approximately 80 MY 2022-2023 Mercedes-
Benz Metris vans. The recall campaign will be visible on the www.safercar.gov website and may generate ques􀆟ons from customers.
All affected VINs will be flagged “OPEN” in VMI and cannot be sold un􀆟l the recall has been remedied.
Background
Issue
Mercedes-Benz AG, the manufacturer of Metris vans, has determined that on certain Metris (447 pla􀆞orm)
vehicles, the fuel pump impeller might not meet specifica􀆟ons in regards to material characteris􀆟cs. As a
consequence, the impeller might deform and come into contact with the fuel pump housing, leading to a
mechanical resistance. In some instances, this could lead to a shutdown of the fuel pump. As a result, the vehicle
could lose propulsion, which could increase the risk of a crash or injury.
What We’re
Doing
MBUSA is conduc􀆟ng a voluntary recall. An authorized Mercedes-Benz dealer will check the fuel delivery module
on the affected vehicles and replace it, if necessary.
Parts Parts are available and can be ordered as necessary.
Vehicles Affected
Vehicle Model
Year(s)
2022-2023
Vehicle Model Metris
Vehicle Popula􀆟ons
Popula􀆟on 80 (vehicles in dealer inventory only)
Dealer Inventory 80
Given this no􀆟ce, it is a viola􀆟on of Federal law for a dealer to sell or lease any new vehicles in dealer inventory covered by this
no􀆟fica􀆟on un􀆟l the vehicle has been repaired.
Loaner and demonstrator vehicles may con􀆟nue to be driven, but must not be retailed un􀆟l repaired.
Addi􀆟onally, given this no􀆟ce, it is a viola􀆟on of Federal Law for rental companies to rent vehicles covered by this no􀆟fica􀆟on un􀆟l
the vehicle has been repaired.
Next Steps/Notes
Customer No􀆟fica􀆟on Timeline Vehicles in dealer inventory only.
AOMS/SOMS AOMs – This recall may generate ques􀆟ons from your dealers. Please forward this no􀆟ce to
your dealers ASAP.
Rental Fleet Partners
This recall may affect vehicles in your fleet. Please contact your respec􀆟ve MBUSA fleet
representa􀆟ve for further informa􀆟on and next steps. For repairs, please contact your
preferred MBUSA dealer.
While we regret any inconvenience this may cause, we are determined to maintain a high level of vehicle quality and customer
sa􀆟sfac􀆟on.
Engine 274 in model 447
Operation no. of the operation texts or standard texts and flat rates
Category Op. no. Operation text Time Damage Code Codeword
P 12 2114 Operations: Replace fuel pump with fuel delivery module 1.3 h 47 902 10 VS2KRAPUM2
P 12 2115 Operations: Extra work for replacing fuel pump with fuel delivery
module for delivery without fill level sensor
0.1 h 47 902 10 VS2KRAPUM2
P 12 2116 Operations: Extra work for emptying fuel pump with fuel delivery
module, replacing fuel tank
0.4 h 47 902 10 VS2KRAPUM2
1 Fuel tank fill level sensor
M3/3 Fuel pump with fuel feed module
S47.20-A027-03
V-RC-2024040005 1
2 Fuel hose
3 Filler neck
S47.20-A028-06
aDanger Risk of explosion caused by fuel igniting,
risk of poisoning caused by inhaling and
swallowing fuel as well as risk of injury to
eyes and skin caused by contactwith fuel.
No fires, sparks, open flames or smoking.
Pour fuels into suitable and appropriately
marked containers only.
Wear protective clothing when handling
fuel.
AS47.00-Z-0001-01A
aCaution Risk of injury caused by scraping or
cutting body parts on sharp vehicle parts
Always wear protective gloves when
working on or near sharp and nondeburred
vehicle parts.
Deburr repair panels.
AS00.00-Z-0017-01A
Notice Notes on avoiding damage through
contamination and foreign objects
AH00.00-P-5000-01A
g Check
1 Check if vehicle is affected by measure.
If the vehicle is affected by the service
measure,
↓
notify vehicle owner that the fuel tank
should only be filled to a maximum of 20%
for the workshop visit for this service
measure (this corresponds to 2 bars on the
fuel display of the instrument cluster).
Preparatory activity
2 Position air extraction system for benzene
fumes in working area and switch on.
A 000 588 00 85 00 Air extraction system WS47.00-P-0039B
2 V-RC-2024040005
Empty the fuel tank
3 Suction off fuel from fuel tank through filler
neck.
Only if fuel tank is filled above 20%.
f AR47.10-S-4001E
e Remove
4 Remove fuel pump with fuel delivery
module (M3/3).
f AR47.20-S-7000E
i
Contrary to the statement in the reference
document on removal of the fuel tank, the
fuel hose (2) does not need to be
removed.
The filler neck (3) is only detached from the
body and remains on the fuel tank.
i
The removed fuel pump with fuel delivery
module (M3/3) is not reused.
Dispose of removed component parts that
are not reused properly. Observe the
applicable legal requirements and
specifications of the relevant country.
Modify
5 Transfer fuel tank fill level sensor (1) of
removed fuel pump with fuel delivery
module (M3/3) to new fuel pump with fuel
delivery module (M3/3).
Only if new fuel pump with fuel delivery
module (M3/3) was delivered without fuel
tank fill level sensor (1).
f AR47.50-S-0111E
d Install
6 Install new fuel pump with fuel delivery
module (M3/3).
f AR47.20-S-7000E
Finishing activity
7 Switch off air extraction system for
benzene fumes and remove from working
area.
Parts ordering note
Part no. Designation Quantity
A 447 470 40 01 Fuel pump with fuel feed module (M3/3) 1
A 025 997 18 45 O-ring 1
– Additional replacement part scopes, small parts and consumable materials required for carrying out
this service measure must be replaced in accordance with the information in the repair documents
referenced in this document. These must be determined according to the vehicle identification number
(FIN) via the “XENTRY Parts Information” system and, whilst not listed in the parts ordering note, they
are included in the costing.
n. B.
V-RC-2024040005 3

**************************************************************************************************************

**************************************************************************************************************
