February, 2024
2024010007
Inspect Frame Reinforcement
This is to notify you of a Recall Campaign to inspect the Frame Reinforcement on approximately 3,602 MY 2019-2022 Mercedes-Benz Sprinter Vans. The recall campaign will be visible on the www.safercar.gov website and may generate questions from customers. All affected VINs will be flagged as “OPEN” in VMI and cannot be sold.
Issue
Mercedes-Benz AG (“MBAG”), the manufacturer of Mercedes-Benz Sprinter Vans, has determined that on certain Sprinter (907 platform) vehicles, the longitudinal frame members of the body-in-white might not meet specifications. Missing reinforcements might lead to damage in the rear area of the longitudinal frame members. Over me, impairment of driving stability cannot be ruled out. In addition, vehicles equipped with a bench seat in the 3rd passenger seat row could experience a failure of the seat mounts in the event of a crash. In this case, the risk of injury would increase.
What We’re Doing
MBUSA will conduct a voluntary recall. As a precautionary measure, an authorized Mercedes-Benz Sprinter dealer will check the longitudinal frame members on the affected vehicles and rework them, if necessary.
Parts
Parts are available and can be ordered as necessary.
Given this noce, it is a violation of Federal law for a dealer to sell or lease any new Sprinter vehicles in dealer inventory covered by this notification unl the vehicle has been repaired.
Loaner and demonstrator vehicles may continue to be driven, but must not be retailed unl repaired.
Additionally, given this noce, it is a violation of Federal Law for rental companies to rent new Sprinter vehicles covered by this notification unl the vehicle has been repaired.
Customer Notification Timeline
An owner notification letter to be mailed in March, 2024.
Repair materials
Order number | Designation | Number |
A 000 986 28 00 09 | 1K-zinc dust paint | BR00.45-Z-1056-07A |
Parts ordering note
Part no. | Designation | Quantity |
A 906 311 06 95 | Front longitudinal member reinforcement | 2 |
A 906 311 01 53 | Rear longitudinal member reinforcement | 2 |
— | Additional replacement part scopes, small parts and consumable materials required for carrying out this service measure must be replaced in accordance with the information in the repair documents referenced in this document. These must be determined according to the vehicle identification number (FIN) via the “XENTRY Parts Information” system and, whilst not listed in the parts ordering note, they are included in the costing. | As Needed |
Inspect Frame Reinforcement
Model 907
Model Years 2019-2022
https://www.startekinfo.com/service/download-document/outside/231426/
- Paint Code - 149 - Polar White
- Touch Up Paint Kit with Brush for Mercedes-Benz Vehicles.
- Single-Stage Application
- Image is Only a Stock Photo
- Repair your ride with TouchUpDirect's touch up paint, the go-to fix for car paint scratch repair. Made with love in sunny SoCal, our high-quality touch up paint for cars and motorcycles gives a durable finish that'll make your vehicle shine and shield it against UV rays. Treat your vehicle right!
- Our car touch up paint is custom-made for DIY enthusiasts, giving you the power to take charge of your vehicle's look. Our auto touch up paint applicators makes repairing paint imperfections simple, giving you the confidence to tackle the job solo. Bid farewell to car paint scratch repair services & hello to a convenient, professional quality solution.
- Rest easy with TouchUpDirect's touch up paint for cars, backed by our Color Match Guarantee to perfectly match your vehicle's color. Remember to use our test card before painting your car, and take some time to get comfortable with our applicators. Should you face any issues or color discrepancies, don't hesitate to contact us for a quick resolution. We're here to help!
- TouchUpDirect's low-VOC environmentally friendly car color paint and automotive clear coat ensure a professional-grade paint job. Each TouchUpDirect automotive touchup paint has everything you’ll need to achieve the best result for your car paint.
- Enough paint to cover at least 10 square inches. Filled with our low-VOC environmentally friendly touch up paint and Clearcoat. This kit includes: One Colorcoat touch up brush that matches the color of your vehicle. One Clearcoat touch up brush for the final finish and protection.
- Precision-Matched OEM Quality Paint: Auto Paint Depot 040 is meticulously crafted to perfectly match the original factory color of your vehicle. Utilizing cutting-edge paint kit computerized technology and advanced production equipment, we ensure a seamless blend of paint with clear coat that meets OEM quality standards, providing an exact match for your vehicle's specific color code.
- Custom-Made for Your Vehicle: Each order of Automotive Clear Coat and Paint is custom matched to your precise factory color code. This means your car paint is manufactured on a per-order basis, guaranteeing that you receive a product tailored specifically to your vehicle's unique color specifications with a clear coat. This level of customization ensures a flawless finish.
- Clear Coat Recommended for Added Protection: For added durability and protection, we recommend applying a clear coat (sold separately) over most Automotive Paint. This extra layer of paint helps to shield your touch-up work from the elements and ensures a long-lasting, professional-quality finish. Consider adding a clear coat from the paint kit to enhance the longevity and resilience of your touch-up paint.
- Versatile Use for Various Repairs: Whether you're addressing minor spots or larger panel repairs, Auto Paint Depot touch-up paint is ideal for a range of repair sizes. This versatility of car paint with a clear coat allows you to tackle different types of scratches, providing a reliable solution for various automotive clear coat paint touch-up projects.
- Clear Coat Recommended for Added Protection: For added durability and protection, we recommend applying a clear coat over most Automotive Paint. This extra layer of paint helps to shield your touch-up work from the elements and ensures a long-lasting, professional-quality finish. Consider adding a clear coat from the paint kit to enhance the longevity and resilience of your touch-up paint.
- Date on bottle is Manufacture date, NOT expiration date**
- 000 986 23 50 5890
- High Quality Part
- Built To Strict Quality Control Standards
- If You Are Unsure If You Car Qualifies, Contact Us with Your Car’s Vin to Verify
- Restore your vehicle with TouchUpDirect's touch up paint, the ultimate car scratch remover. Made with love in sunny SoCal, our premium scratch remover for vehicles and motorcycles delivers a durable finish that enhances your vehicle's shine while providing protection against harmful UV rays. Give your vehicle the treatment it deserves!
- Our touch up paint for cars is designed specifically for DIY enthusiasts, giving you power to transform your vehicle's look. Our user-friendly applicators simplify the process of correcting paint imperfections, enabling you to tackle the job solo. Bid farewell to expensive auto paint services and embrace a convenient, DIY-friendly solution.
- Feel confident with TouchUpDirect's automotive paint, supported by our Color Match Guarantee ensuring an exact match to your vehicle's color. Prior to starting your car paint repair, utilize our test card and familiarize yourself with our touch up paint kit applicators. Rest assured, we're here to assist with any concerns or color variations.
- TouchUpDirect provides low-VOC, environmentally friendly Colorcoat auto touch up paint and Clearcoat with professional-quality paint finishes. All the components required to obtain the best possible results for your car paint are included in our comprehensive car scratch repair kit.
- The Aerosol essential touch up paint kit includes: Color coat and automotive clear coat Aerosol spray can. clear coat paint for cars is a vital and required step in any auto paint job. It is the final layer of any modern paint finish, adding factory gloss & protection. Paint coverage: 3-4 cans for hoods/trunk lids, 2-3 cans for bumpers, 1 can for mirrors.
- COLOR MATCH GUARANTEED: Our paint will match your vehicle's original finish.
- EASY TO USE: Detailed instructions take out all the guesswork.
- MULTIPLE APPLICATORS: Because scratches come in different shapes and sizes.
- ESSENTIAL PACKAGE: Paint/Clear Coat Bottles (0.5 fl. oz. each) + Applicators (4 sizes, 14 units).
- MADE IN USA: Manufactured in a solar-powered factory in Salt Lake City, Utah.
- COLOR MATCH GUARANTEED: Our paint will match your vehicle's original finish.
- EASY TO USE: Detailed instructions take out all the guesswork.
- MULTIPLE APPLICATORS: Because scratches come in different shapes and sizes.
- ESSENTIAL PACKAGE: Paint/Clear Coat Bottles (0.5 fl. oz. each) + Applicators (4 sizes, 14 units).
- MADE IN USA: Manufactured in a solar-powered factory in Salt Lake City, Utah.
- 000 986 21 50 9149
- High Quality Part
- Built To Strict Quality Control Standards
- If You Are Unsure If You Car Qualifies, Contact Us with Your Car’s Vin to Verify
Last update on 2024-04-02 / Affiliate links / Images from Amazon Product Advertising API
This product presentation was made with AAWP plugin.
SEOCONTENT-START
TO: Mercedes-Benz Dealer Principals, General
Managers, Sales Managers, Service Managers,
Parts Managers
FROM: Anthony Washington, Senior Manager,
Regulaons and Cerficaons
Re: Launch Recall Campaign Noficaon
Model 907 Sprinter
Model Years 2019-2022
Inspect Frame Reinforcement
DATE: February, 2024
IMPORTANT RECALL CAMPAIGN INFORMATION
Please see the atached documents related to the campaign listed above.
Campaign No. : Campaign Desc. : Inspect Frame Reinforcement 2024010007 VS3ROHRAH
This is to nofy you of a Recall Campaign to inspect the Frame Reinforcement on approximately 3,602 MY 2019-2022 Mercedes-Benz
Sprinter Vans. The recall campaign will be visible on the www.safercar.gov website and may generate quesons from customers. All
affected VINs will be flagged as “OPEN” in VMI and cannot be sold.
Background
Issue
Mercedes-Benz AG (“MBAG”), the manufacturer of Mercedes-Benz Sprinter Vans, has determined that on
certain Sprinter (907 plaorm) vehicles, the longitudinal frame members of the body-in-white might not
meet specificaons. Missing reinforcements might lead to damage in the rear area of the longitudinal
frame members. Over me, impairment of driving stability cannot be ruled out. In addion, vehicles
equipped with a bench seat in the 3rd passenger seat row could experience a failure of the seat mounts
in the event of a crash. In this case, the risk of injury would increase.
What We’re Doing
MBUSA will conduct a voluntary recall. As a precauonary measure, an authorized Mercedes-Benz
Sprinter dealer will check the longitudinal frame members on the affected vehicles and rework them, if
necessary.
Parts Parts are available and can be ordered as necessary.
Vehicles Affected
Vehicle Model Year(s) 2019-2022
Vehicle Model Sprinter
Vehicle Populaons
Populaon 3,602
Dealer Inventory 0
Given this noce, it is a violaon of Federal law for a dealer to sell or lease any new Sprinter vehicles in dealer inventory covered
by this noficaon unl the vehicle has been repaired.
Loaner and demonstrator vehicles may connue to be driven, but must not be retailed unl repaired.
Addionally, given this noce, it is a violaon of Federal Law for rental companies to rent new Sprinter vehicles covered by this
noficaon unl the vehicle has been repaired.
Next Steps/Notes
Customer Noficaon Timeline An owner noficaon leter to be mailed in March, 2024.
AOMS/SOMS AOMs – This recall may generate quesons from your dealers. Please forward this
noce to your dealers ASAP.
Rental Fleet Partners
This recall may affect vehicles in your fleet. Please contact your respecve MBUSA fleet
representave for further informaon and next steps. For repairs, please contact your
preferred MBUSA dealer.
While we regret any inconvenience this may cause, we are determined to maintain a high level of vehicle quality and customer
sasfacon.
Model 907.6##/7## #T
with code V40 (Crew cab floor assy)
Operation no. of the operation texts or standard texts and flat rates
Category Op. no. Operation text Time Damage Code Codeword
L 12 1609 Operations: Subsequently reinforce 2 longitudinal
frame members
14.3 hrs 3190304 VS3ROHRAH
D61.25-A014-79
1 Vehicle floor a Dimension (width of crease)
1.1 Sections b Dimension (approx. 120 mm)
01 Welding protection blanket d Dimension (approx. 190 mm)
V-RC-2024010007 1
c Dimension (approx. 565 mm)
D61.25-A024-76
D61.25-A013-78
1 Vehicle floor 3 Reinforcements
2 Reinforcements 01 Welding protection blanket
2 V-RC-2024010007
aDanger The high voltage used for electric
welding presents a lethal hazard.
Risk of explosion from welding in
areas close to highly inflammable
materials. Risk of injury from
weld splatter and UV-light when
welding. Risk of poisoning from
inhaling welding gases
Use insulating mats. Wear
protective clothing, safety glasses
and a protective mask. Remove
highly inflammable materials from
the hazard area. Use air extraction
system.
AS00.00-Z-0007-01A
aCaution Risk of injury caused by scraping
or cutting body parts on sharp
vehicle parts
Always wear protective gloves
when working on or near sharp
and non-deburred vehicle parts.
Deburr repair panels.
AS00.00-Z-0017-01A
Notice Measures for preventing damage
to vehicles or components when
performing electric welding work
AH00.00-P-0005-01KOA
Notice Notes on battery AH54.10-P-0001-01A
Notice General information on body repair AH60.00-P-0001-01KOA
Notice Notes on carrying out repair work
in the vehicle interior
AH68.00-D-0001-01KOS
g Check
1 Check whether vehicle is affected
by measure.
Clip: Subsequently reinforce Page 7
longitudinal frame member (code:
VS3ROHRAH, acc. no.: 31 903 04)
i
A video with a simplified
presentation is available for this
measure. Nevertheless, all work
instructions and information in
this document are to be
observed as a matter of priority.
e Remove
2 Remove passenger bench seat.
f Model 907.6##/7## #T with
passenger compartment seating
AR91.21-D-4425TS
3 Remove seat anchorages for
passenger bench seat/passenger
bench seats.
f AR91.21-D-3772TSR
4 Remove B-pillar trim on driver’s
side.
f Model 907.7 AR68.30-D-4707TS
f Remove/install B-pillar trim Model 907.6 AR68.30-D-4705TS
V-RC-2024010007 3
5 Remove B-pillar trim on front
passenger side.
f Model 907.7 AR68.30-D-4706TS
f Remove/install B-pillar trim Model 907.6 AR68.30-D-4705TS
6 Remove D-pillar trim.
f AR68.30-D-4497TSR
7 Remove floor covering in
passenger compartment.
f AR68.80-D-0012TSR
Retrofit reinforcements
8 Scribe separation lines on vehicle
floor (1).
i
The width of the cutout is based on
the laser weld seams (A).
The length of the cutout is based
on the chamfer (D).
Dimension a: 70 mm
Dimension b: 120 mm
Dimension d: 180 mm
9 Cover all detachable parts
remaining in vehicle with welding
protection blankets (01).
i
Commercially available devices/
tools
Welding protection blanket
10 Detach vehicle floor (1). p
Do not make the cuts too deep.
This prevents damage to the
component parts located
underneath.
11 Remove sections (1.1). i
Do not dispose of sections (1.1).
12 Clean weld joints and sheet metal
flange.
i
Commercially available devices/
tools
Rotary wire brush
13 Retrofit reinforcements (2, 3). Page 8
A 000 588 02 84 00 Welder WS60.00-P-0022K
i
For reinforcements (3), observe
dimension c: 565 mm.
i
Commercially available devices/
tools
Clamping pliers (Standard)
Smoke extraction
Rotary wire brush
1K-zinc dust paint BR00.45-Z-1056-07A
14 Insert vehicle floor (1).
A 000 588 02 84 00 Welder WS60.00-P-0022K
4 V-RC-2024010007
15 Clean weld joints and sheet metal
flange.
i
Commercially available devices/
tools
Clamping pliers (Standard)
Smoke extraction
Rotary wire brush
16 Remove welding protection
blankets.
aDanger Risk of explosion caused by
paint vapors igniting. Risk of
poisoning caused by inhaling
paint vapors.
No smoking! No open fire! Use
respiratory protection, protective
clothing, gloves, safety glasses
and protective skin cream. Ensure
that the area is well ventilated.
AS98.00-Z-0002-01A
17 Prime repair area with primer filler.
Notice Notes on paintwork repairs AH98.00-P-9408-02A
i
Use only primer fillers approved by
manufacturer.
See guidelines for paint technology
in the workshop portal.
aDanger Risk of explosion caused by
paint vapors igniting. Risk of
poisoning caused by inhaling
paint vapors.
No smoking! No open fire! Use
respiratory protection, protective
clothing, gloves, safety glasses
and protective skin cream. Ensure
that the area is well ventilated.
AS98.00-Z-0002-01A
18 Paint repair area and adjacent
surfaces.
Notice General notes on touch-up
applicators and paint spray cans
AH98.00-P-9409-06A
Notice Notes on paintwork repairs AH98.00-P-9408-02A
i
Use only paints approved by
Daimler AG.
See guidelines for paint technology
in the workshop portal.
19 Add cavity preservation to repair
area.
f AR97.20-D-1500TS
d Install
20 Install floor covering in passenger
compartment.
f AR68.80-D-0012TSR
21 Install D-pillar trim.
f AR68.30-D-4497TSR
22 Install B-pillar trim on front
passenger side.
f Model 907.7 AR68.30-D-4706TS
f Remove/install B-pillar trim Model 907.6 AR68.30-D-4705TS
V-RC-2024010007 5
23 Install B-pillar trim on driver’s side.
f Model 907.7 AR68.30-D-4707TS
f Remove/install B-pillar trim Model 907.6 AR68.30-D-4705TS
24 Install seat anchorages for
passenger bench seat/passenger
bench seats.
f AR91.21-D-3772TSR
25 Install passenger bench seat.
f Model 907.6##/7## #T with
passenger compartment seating
AR91.21-D-4425TS
Repair materials
Order number Designation Number
A 000 986 28 00 09 1K-zinc dust paint BR00.45-Z-1056-07A
Parts ordering note
Part no. Designation Quantity
A 906 311 06 95 Front longitudinal member reinforcement 2
A 906 311 01 53 Rear longitudinal member reinforcement 2
— Additional replacement part scopes, small parts and consumable materials required
for carrying out this service measure must be replaced in accordance with the
information in the repair documents referenced in this document. These must be
determined according to the vehicle identification number (FIN) via the “XENTRY
Parts Information” system and, whilst not listed in the parts ordering note, they are
included in the costing.
As Needed
6 V-RC-2024010007
GB61.25-D-0000-00A Clip: Subsequently reinforce
longitudinal frame member
(code: VS3ROHRAH, acc. no.:
31 903 04)
Model 907.6##/7## #T
with code V40 (Crew cab floor assy)
wsm://04_202400_04
V-RC-2024010007 7
SM61.25-D-0006-02SGG Retrofit reinforcements in
longitudinal frame members
(code: VS3ROHRAH, acc. no.:
31 903 04)
aDanger Risk of explosion caused by
paint vapors igniting. Risk of
poisoning caused by inhaling
paint vapors.
No smoking! No open fire! Use
respiratory protection,
protective clothing, gloves,
safety glasses and protective
skin cream. Ensure that the
area is well ventilated.
AS98.00-Z-0002-01A
aDanger Risk of explosion and
poisoning caused by solvent
vapors and gasses. Risk of
injury to skin and eyes when
working with anticorrosion
agents
Never spray corrosion
protection on flames or hot,
glowing objects and keep them
well away from all potential
sources of ignition. Use them
only in well-ventilated rooms;
wear respiratory protection.
AS97.00-Z-0001-01A
aDanger The high voltage used for
electric welding presents a
lethal hazard. Risk of
explosion from welding in
areas close to highly
inflammable materials. Risk of
injury from weld splatter and
UV-light when welding. Risk of
poisoning from inhaling
welding gases
Use insulating mats. Wear
protective clothing, safety
glasses and a protective mask.
Remove highly inflammable
materials from the hazard
area. Use air extraction
system.
AS00.00-Z-0007-01A
aCaution Risk of injury caused by
scraping or cutting body parts
on sharp vehicle parts
Always wear protective gloves
when working on or near sharp
and non-deburred vehicle
parts.
Deburr repair panels.
AS00.00-Z-0017-01A
Notice Notes on paintwork repairs AH98.00-P-9408-02A
Notice Notes on cavity preservation AH97.20-P-0001-01B
Notice Notes on carrying out repair
work in the vehicle interior
AH68.00-D-0001-01KOS
Notice General information on body
repair
AH60.00-P-0001-01KOA
Notice Measures for preventing
damage to vehicles or
components when performing
electric welding work
AH00.00-P-0005-01KOA
Notice Notes on paintwork repairs AH98.00-P-9408-02A
General information on
operation items and work
procedures for painting
AH98.00-P-0003-01A
Model 907.6##/7## #T
with code V40 (Crew cab floor assy)
Prepare vehicle floor sections
8 V-RC-2024010007
1 Grind mating
surfaces in the
cross-hatched areas
on sections (1.1, 1.2)
of vehicle floor down
to bare metal.
2 Remove shavings.
D61.25-A015-76
Prepare reinforcements for installation
3 Grind mating surfaces in the crosshatched
areas on reinforcements (2, 3)
down to bare metal.
4 Remove shavings.
D61.25-A016-82
– – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – –
Prepare longitudinal members
V-RC-2024010007 9
D61.25-A017-79
5 Grind mating surfaces in the crosshatched
areas on longitudinal members
(1) down to bare metal.
6 Remove shavings.
Prepare vehicle floor
D61.25-A018-77
7 Grind mating surfaces in cross-hatched
areas on vehicle floor (4) down to bare
metal.
8 Remove shavings.
Install reinforcements
10 V-RC-2024010007
D61.25-A019-79
9 Position reinforcements (2, 3) in
longitudinal member (1).
i
Reinforcements (2): A 906 311 06 95
Reinforcements (3): A 906 311 01 53
i
Observe dimension (C) here. Dimension
(C) is 565 mm.
10 Reinforcements (2, 3) k f (areas D,
E).
i
Inert gas weld in intervals and allow to
cool down in between. This reduces the
heat distortion.
V-RC-2024010007 11
D61.25-A020-79
11 Clean weld joints and sheet metal
flanges in cross-hatched area.
12 Prime repair area with a primer filler.
i
Use only primer fillers approved by
manufacturer.
See guidelines for paint technology in
the workshop portal.
12 V-RC-2024010007
Install sections
1.1 Part section
1.2 Part section
4 Vehicle floor
D61.25-A021-76
D61.25-A022-79
13 Position sections (1.1, 1.2) on vehicle
floor (3).
14 Tack sections (1.1, 1.2) k e into place.
15 Sections (1.1, 1.2) k f (areas F, G).
i
Inert gas weld in intervals and allow to
cool down in between. This reduces the
heat distortion.
V-RC-2024010007 13
16 Grind inert gas weld down flat (areas F,
G).
17 Remove shavings.
D61.25-A023-79
18 Clean weld joints and sheet metal
flange.
19 Prime repair area with a primer filler.
i
Use only primer fillers approved by
manufacturer.
See guidelines for paint technology in
the workshop portal.
20 Paint repair area and adjacent surfaces.
i
Only use paints approved by the
manufacturer.
See guidelines for paint technology in
the workshop portal.
14 V-RC-2024010007
**************************************************************************************************************
**************************************************************************************************************
SEOCONTENT-END
