Mercedes-Benz USA, LLC A Mercedes-Benz Group AG Company
One Mercedes-Benz Drive Sandy Springs, GA 30328 770.705.0600
News Channel Update | Vehicle Compliance & Analysis
IMPORTANT SERVICE CAMPAIGN LAUNCH
Please note that all customer inquiries should be directed to the Customer Assistance Center at 1-800-FOR-MERCEDES (1-800-367-6372).
Sincerely,
Gregory Gunther
Department Manager, Vehicle Compliance & Analysis
TO: Mercedes-Benz Dealer Principals, General Managers, Sales Managers, Service Managers, Parts Managers
FROM: Gregory Gunther, Department Manager, Vehicle Compliance and Analysis, Engineering Services
RE: Service Campaign Launch Notification
Check Front Diffuser Attachment Point Seal
MY21 GT Black Series (190 platform)
DATE: April 28, 2023
Mercedes-Benz USA, LLC A Mercedes-Benz Group AG Company
One Mercedes-Benz Drive Sandy Springs, GA 30328 770.705.0600
News Channel Update | Vehicle Compliance & Analysis
Service Campaign Launch Notification April 28, 2023
Campaign No. :
Campaign Desc. :
Check Front Diffuser Attachment Point Seal
2023030016
22P8891008
This is to notify you of the Service Campaign Launch to check the front diffuser on 379 Model Year (“MY”) 2021 GT Black Series (190 platform) vehicles. The vehicles will be visible and flagged in VMI as “OPEN” on April 28, 2023.
Background
Issue
Mercedes-Benz AG (“MBAG”), the manufacturer of Mercedes-Benz vehicles, has determined that on certain MY 2021 GT (190 platform) vehicles, the front diffuser may not meet current production specifications.
What We’re Doing
MBUSA will conduct a service campaign. An authorized Mercedes-Benz dealership will check the front diffuser attachment point seals and replace or repair as necessary. Parts The remedy is available and can be performed as necessary.
Vehicles Affected
Vehicle Model Year(s)
2021
Vehicle Model
GT Black Series
Vehicle Populations
Total Campaign Population
379
Next Steps/Notes
AOMS/SOMS
AOMs – This campaign may generate questions from your dealers.
While we regret any inconvenience this may cause, MBUSA is determined to maintain a high level of vehicle quality and customer satisfaction. Please refer all customer inquiries to the Customer Assistance Center at 1-800-FOR-MERCEDES.
2
Campaign No. 2023030016, April 2023
TO: ALL MERCEDES-BENZ CENTERS
SUBJECT: Model GT (190 platform)
Model Year 2021
Check Front Diffuser Attachment Point Seal
Mercedes-Benz AG (“MBAG”), the manufacturer of Mercedes-Benz vehicles, has determined that on certain MY 2021 GT (190 platform) vehicles, the front diffuser may not meet current production specifications. An authorized Mercedes-Benz dealership will check the front diffuser attachment point seals and replace or repair as necessary.
Prior to performing this Campaign:
VMI must be checked before performing campaigns to verify that the campaign is required ona specific vehicle. Always check for any other open campaigns, and perform accordingly.
Please review the entire Campaign bulletin and follow the repair procedure exactly asdescribed.
Approximately 379 vehicles are affected. Order No. P-SC-2023030016
2
P-SC-2023030016
Check front diffuser, replace or seal if necessary
Check/test procedure A 1. Remove lower front diffuser (A, Figure 1).
For basic data, see AR61.20-P-1105RG.
Figure 1 2. Check the 5 threaded connections (A, Figure 2) of the removed front diffuser for corrosion.
Figure 2
3
P-SC-2023030016
Figure 3 → Areas are corroded (not OK)
Figure 4 → Areas are not corroded (OK)
Figure 3 (areas are corroded = not OK) Figure 4 (areas are not corroded = OK)
a. Areas are corroded (Figure 3): Carry out work procedure A. b. Areas are not corroded (Figure 4): Carry out Check/test procedure B.
Check/test procedure B 1. Check the removed front diffuser to see whether all 16 (blue aramid pads) are bonded in the marked places (Figure 5).
Figure 5
a. All 16 (aramid pads) are present (Figure 5): Carry out work procedure B. b. All 16 (aramid pads) are not present (Figures 11 and 12): Perform work procedure B and C.
4
P-SC-2023030016
Work procedure A
1. Replace front diffuser.
For basic data, see AR61.20-P-1105RG.
Work procedure B
1. Clean all 5 attachment points (Figure 2) of the front diffuser with isopropanol and let dry (Figure 6).
Figure 6
2. Fill all 5 attachment points around the decoupling disc with a bead of Teroson (Figures 7 and 8).
Figure 7 Figure 8
5
P-SC-2023030016
3. Spread/pull off the Teroson bead to the surface of the decoupling disk (Figure 9).
The Teroson bead must not protrude more than 1.5 mm beyond the disk.
Ensure that there is no Teroson on the screw-mounting surface; clean if necessary.
Let Teroson harden as per specifications.
Figure 9
4. Reinstall front diffuser.
For basic data, see AR61.20-P-1105RG.
5. Assemble in reverse order.
6
P-SC-2023030016
Work procedure C
1. Clean the marked attachment points (16 points, Figure 10) of the front diffuser with isopropanol and allow to dry completely (Figure 11).
Figure 10
Figure 11
2. Center and attach a self-adhesive aramid pad to all 16 attachment points; ensure adhesion by pressing down and all around the aramid pad using your thumb (Figure 12&13).
Figure 12 Figure 13
3. Assemble in reverse order.
7
P-SC-2023030016
Primary Parts Information
Qty. Part Name Part Number
As required*
Front diffuser
A 190 520 21 00
As required LU adhesive sealing disk (aramid pads)
A 190 989 00 00
As required**
Teroson
A 000 989 46 06
* The replacement parts must be determined according to the equipment variant for the vehicle identification number via the parts process in the Xentry Portal.
** 1 packaging unit must be used for approx. 10 vehicles and has to be claimed as quantity 0.1
Small parts such as screws, lock nuts, sealing rings, cable ties, fluids, sealant, etc. are not listed in the parts list. The required small parts are taken into account in the budgeting.
__________________________________________________________________________________________________
Note: The following allowable labor operation should be used when submitting a warranty claim for this repair:
Warranty Information
Damage Code Operation Number Description Labor Time (hrs.)
88 910 08
02-0248
Check front diffuser Check/test procedures A and B Includes: Remove front diffuser and check for corrosion, and check all 16 points (blue aramid pads)
0.4
02-0249 Replace front diffuser (after check) Work procedure A
0.7
02-0250 Seal front diffuser (after check) Work procedure B All 16 aramid pads are present
Includes: Clean 5 attachment points on front diffuser and seal with Teroson
0.2
02-0251 Rework front diffuser (after check) Work procedures B and C All 16 aramid pads are not present
Includes: Clean 5 attachment points on front diffuser and seal with Teroson, and clean 16 attachment points on front diffuser and install aramid pads
0.9
Note: Always check Xentry Operation Time (XOT) for the current OP-Code times. Labor times are subject to change and updates may not be reflected in this document.

**************************************************************************************************************

Mercedes-Benz USA, LLC A Mercedes-Benz Group AG Company
One Mercedes-Benz Drive Sandy Springs, GA 30328 770.705.0600
News Channel Update | Vehicle Compliance & Analysis
IMPORTANT SERVICE CAMPAIGN UPDATE
Please note that all customer inquiries should be directed to the Customer Assistance Center at 1-800-FOR-MERCEDES (1-800-367-6372).
Sincerely,
Gregory Gunther
Senior Manager, Vehicle Compliance & Analysis
TO: Mercedes-Benz Dealer Principals, General Managers, Sales Managers, Service Managers, Parts Managers
FROM: Gregory Gunther, Senior Manager, Vehicle Compliance and Analysis, Engineering Services
RE: Service Campaign Update Notification
Check Front Diffuser Attachment Point Seal
Temporary Campaign Deactivation
MY21 GT Black Series (190 platform)
DATE: July 21, 2023
Mercedes-Benz USA, LLC A Mercedes-Benz Group AG Company
One Mercedes-Benz Drive Sandy Springs, GA 30328 770.705.0600
News Channel Update | Vehicle Compliance & Analysis
Service Campaign Update Notification July 21, 2023
Campaign No. :
Campaign Desc. :
Check Front Diffuser Attachment Point Seal Temporary Campaign Deactivation
2023030016
22P8891008
This is to notify you of a Service Campaign Update to check the front diffuser on 379 Model Year (“MY”) 2021 GT Black Series (190 platform) vehicles. The vehicles are visible and were flagged in VMI as “OPEN” on April 28, 2023.
The campaign was deactivated on July 18, 2023 and will be reactivated once revised work instructions are issued.
Background
Issue
Mercedes-Benz AG (“MBAG”), the manufacturer of Mercedes-Benz vehicles, has determined that on certain MY 2021 GT (190 platform) vehicles, the front diffuser may not meet current production specifications.
What We’re Doing
The campaign has been deactivated pending new work instructions. Approximate re-launch timeline is mid-August 2023. Once new work instructions are issued, the campaign will be reactivated and the field will be informed accordingly.
Claims for repairs:
RO open dates on or prior to July 20, 2023 will be accepted. If any errors occur, please open a Warranty OneTrac case for issue resolution. Parts Remedy is not available.
Vehicles Affected
Vehicle Model Year(s)
2021
Vehicle Model
GT Black Series
Vehicle Populations
Total Campaign Population
379
Next Steps/Notes
AOMS/SOMS
AOMs – This campaign may generate questions from your dealers.
While we regret any inconvenience this may cause, MBUSA is determined to maintain a high level of vehicle quality and customer satisfaction. Please refer all customer inquiries to the Customer Assistance Center at 1-800-FOR-MERCEDES.

**************************************************************************************************************

Mercedes-Benz USA, LLC A Mercedes-Benz Group AG Company
One Mercedes-Benz Drive Sandy Springs, GA 30328 770.705.0600
News Channel Update | Vehicle Compliance & Analysis
IMPORTANT SERVICE CAMPAIGN LAUNCH
Please note that all customer inquiries should be directed to the Customer Assistance Center at 1-800-FOR-MERCEDES (1-800-367-6372).
Sincerely,
Gregory Gunther
Department Manager, Vehicle Compliance & Analysis
TO: Mercedes-Benz Dealer Principals, General Managers, Sales Managers, Service Managers, Parts Managers
FROM: Gregory Gunther, Department Manager, Vehicle Compliance and Analysis, Engineering Services
RE: Service Campaign Launch Notification
Check Front Diffuser Attachment Point Seal
MY21 GT Black Series (190 platform)
DATE: April 28, 2023
Mercedes-Benz USA, LLC A Mercedes-Benz Group AG Company
One Mercedes-Benz Drive Sandy Springs, GA 30328 770.705.0600
News Channel Update | Vehicle Compliance & Analysis
Service Campaign Launch Notification April 28, 2023
Campaign No. :
Campaign Desc. :
Check Front Diffuser Attachment Point Seal
2023030016
22P8891008
This is to notify you of the Service Campaign Launch to check the front diffuser on 379 Model Year (“MY”) 2021 GT Black Series (190 platform) vehicles. The vehicles will be visible and flagged in VMI as “OPEN” on April 28, 2023.
Background
Issue
Mercedes-Benz AG (“MBAG”), the manufacturer of Mercedes-Benz vehicles, has determined that on certain MY 2021 GT (190 platform) vehicles, the front diffuser may not meet current production specifications.
What We’re Doing
MBUSA will conduct a service campaign. An authorized Mercedes-Benz dealership will check the front diffuser attachment point seals and replace or repair as necessary. Parts The remedy is available and can be performed as necessary.
Vehicles Affected
Vehicle Model Year(s)
2021
Vehicle Model
GT Black Series
Vehicle Populations
Total Campaign Population
379
Next Steps/Notes
AOMS/SOMS
AOMs – This campaign may generate questions from your dealers.
While we regret any inconvenience this may cause, MBUSA is determined to maintain a high level of vehicle quality and customer satisfaction. Please refer all customer inquiries to the Customer Assistance Center at 1-800-FOR-MERCEDES.
2
Campaign No. 2023030016, April 2023 Revision A: 01/17/2024
TO: ALL MERCEDES-BENZ CENTERS
SUBJECT: Model GT (190 platform)
Model Year 2021
Check Front Diffuser Attachment Point Seal
Mercedes-Benz AG (“MBAG”), the manufacturer of Mercedes-Benz vehicles, has determined that on certain MY 2021 GT (190 platform) vehicles, the front diffuser may not meet current production specifications. An authorized Mercedes-Benz dealership will check the front diffuser attachment point seals and replace or repair as necessary.
Prior to performing this Campaign:
• VMI must be checked before performing campaigns to verify that the campaign is required on a specific vehicle. Always check for any other open campaigns, and perform accordingly.
• Please review the entire Campaign bulletin and follow the repair procedure exactly as described.
Approximately 379 vehicles are affected.
Order No. P-SC-2023030016
2
P-SC-2023030016
Check front diffuser, replace or seal if necessary
The work instructions have been completely re-worked, please read in its entirety.
Modification notes:
• Creation of TIPS case mandatory in case of parts replacement!
• No front diffuser upper part may be replaced without the relevant approval via a TIPS case!
• Please address TIPS cases with informative images directly to the Product Support AMG / AMG Aftersales Regulation TEV/OPT.
• OK and not OK assessment images included for establishment of findings. • Tightening torque entered for fillister head screws at front diffuser.
• Parts table expanded and updated.
• Code M032 corresponds to the BLACK SERIES VERSION.
Check/test procedure A 1. Remove lower front diffuser (A, figure 1). For basic data, see AR61.20-P-1105RG.
Figure 1 2. Clean 5 threaded connection points (figure 2) of removed front diffuser with isopropanol and check for corrosion.
Figure 2
A
A
3
P-SC-2023030016
Figure 3, not OK Figure 3 → Metal inserts are corroded (not OK)
Figure 4, OK Figure 4 → Metal inserts are not/slightly corroded at edge (OK)
a. Metal inserts are severely corroded (figure 3): Perform work procedure A. b. Metal inserts are not and/or only slightly corroded at the edge (figure 4): Perform check/test procedure B
A reworking of the front diffuser shall be preferred!
The front diffuser is solely approved with informative images directly via a TIPS case by the Product Support AMG / AMG Aftersales Regulation TEV/OPT.
4
P-SC-2023030016
Check/test procedure B
1. Check the removed front diffuser to see whether all 16 (blue aramid pads) are affixed to the marked locations (figure 5).
Figure 5
a. All 16 (aramid pads) are present (figure 5): Carry out work procedure B. b. All 16 (aramid pads) are not present (figures 11 and 12): Perform work procedures B and C.
5
P-SC-2023030016
Work procedure A
1. Remove clips and plastic protective strip in order to release the sealing lip (B, figure 6).
Figure 6
2. Unclip cables on right and left (figure 7).
Figure 7 3. Remove screws for front diffuser lip, retaining straps and diffuser guide (figure 8).
Fillister head screws to front diffuser 6 Nm
B
B
6
P-SC-2023030016
Figure 8
4. Disassemble both spring elements (figure 9).
Figure 9
7
P-SC-2023030016
5. Disassemble both diffuser guides (figure 10).
Figure 10
6. Carefully pull apart front diffuser upper and lower parts (figure 11).
Figure 11
7. Reassemble new part in reverse order.
8. Reinstall front diffuser. For basic data, see AR61.20-P-1105RG.
8
P-SC-2023030016
Work procedure B
1. Clean all 5 attachment points (figure 2) of front diffuser with isopropanol and allow to dry (figure 12)
Figure 12
2. Fill all 5 attachment points around the decoupling disks with Teroson bead (figures 13 and 14).
Figure 13 Figure 14
3. Spread/remove Teroson bead to/from surface of decoupling disk (figure 15).
Terson bead may not protrude by more than 1.5 mm beyond the disk.
Ensure there is no Teroson on the screw-on surface, clean if necessary.
Allow Teroson to cure according to the specification.
9
P-SC-2023030016
Figure 15
4. Reinstall front diffuser. For basic data, see AR61.20-P-1105RG.
5. Assemble in reverse order.
10
P-SC-2023030016
Work procedure C
1. Clean 16 marked attachment points (figure 16) of front diffuser with isopropanol and allow to dry (figure 17)
Figure 16
Figure 17
2. Affix the self-adhesive aramid pads as centrally as possible on all 16 dried attachment points and press on all round with your thumb (figure 18 and 19).
Figure 18 Figure 19
3. Assemble in reverse order.
11
P-SC-2023030016
Primary Parts Information
Qty. Part Name Part Number
As required*
Front diffuser upper part
A 190 520 24 00
As required LU adhesive sealing disk (aramid pads)
A 190 989 00 00
As required**
Teroson
A 000 989 46 06
As required**
Isopropanol
A 005 989 19 71
* The replacement parts must be determined according to the equipment variant for the vehicle identification number via the parts process in the Xentry Portal.
** 1 packaging unit must be used for approx. 10 vehicles and has to be claimed as quantity 0.1
Small parts such as screws, lock nuts, sealing rings, cable ties, fluids, sealant, etc. are not listed in the parts list. The required small parts are taken into account in the budgeting.
__________________________________________________________________________________________________
Note: The following allowable labor operation should be used when submitting a warranty claim for this repair:
Warranty Information
Damage Code Operation Number Description Labor Time (hrs.)
88 910 08
02-0248
Check front diffuser
Check/test procedures A and B
Includes: Remove front diffuser, clean with isopropanol and check for corrosion, as well as check all 16 pieces (blue aramid pads)
0.6
02-0249
Partially replace front diffuser (after check)
Work procedure A
0.9
02-0250 Seal front diffuser (after check) Work procedure B All 16 aramid pads are present
Includes: Clean 5 attachment points on front diffuser and seal with Teroson
0.2
02-0251 Rework front diffuser (after check) Work procedures B and C All 16 aramid pads are not present
Includes: Clean 5 attachment points on front diffuser and seal with Teroson, and clean 16 attachment points on front diffuser and install aramid pads
0.9
02-2186
Create TIPS case
0.2
Note: Always check Xentry Operation Time (XOT) for the current OP-Code times. Labor times are subject to change and updates may not be reflected in this document.

SEOCONTENT-END
