Replace Folding Parking Brake Lever Label – 2019 Mercedes-Benz Sprinter

SEOCONTENT-STARTThis bulletin has been created and maintained in accordance with MBUSA-SLP S423QH001, Document and Data
Control, and MBUSA-SLP S424HH001, Control of Quality Records.
Model 907
with code BE2 (Handbrake lever, folding)
with code ZU8 (National version for USA)
Operation no. of the operation texts or standard texts and flat rates
Category Op. no. Operation text Time Acc. no. Code
L 02 1193 Operations: Replace information label for folding
parking brake lever
0.2 hrs 42 930 93 VS3FOLEV
ER
23 Information label
D00.10-A074-03
g Check
1 Check, whether the vehicle is
affected by the measure.
i
For authorized Mercedes‑Benz
service partners, only the entry in
the Extended VEGA Application
(EVA) system, in the “Current” tab,
is decisive. An additional test of the
affected vehicles in the workshop
information system (WIS) or
vehicle list is thereby not
necessary.
V-SC-2021010002 1
Replace
2 Replace information label (23) for
folding parking brake lever.
p
Bonding surface must be
absolutely free of dust and grease.
Otherwise, a sufficient degree of
adhesion cannot be assured.
i
The information label (23) is
located next to the start/stop
button.
Cleaner BR00.45-Z-1025-04A
Repair materials
Number Designation Order number
BR00.45-Z-1025-04A Cleaner A 005 989 19 71
Parts ordering note
Part no. Designation Quantity
A 906 584 85 07 Information label n. B.
2 V-SC-2021010002
