Replace Front Axle Air Suspension Struts - 2020 Mercedes-Benz GLS-Class (X167)

“This site contains affiliate links for which OEMDTC may be compensated”

WORK DESCRIPTION FOR FIELD MEASURE

Version: 2.0

Code: 19P3296001

Replace front axle air suspension struts
Model 167

Work procedure

1. Replace front axle air suspension struts (AR32.25-P-1017ME).

Parts

Quantity	Designation	Part no.
1	Left front air suspension strut	A 167 320 05 031
1	Right front air suspension strut	A 167 320 06 03

Small parts such as screws, self-locking nuts, sealing rings, cable ties, fluids, sealants, etc. are not listed in the parts list. The required small parts are taken into account in the budgeting.

Operation text and flat rate

Operation

Operation text

Flat rate

Accounting no./
damage code

02-1450

Replace 2 suspension struts of front axle

Includes: Remove/install suspension struts; replace front suspension struts; depressurize/pressurize suspension struts; remove/install 2 wheel and tire assemblies; connect wheels-free jack, diagnosis; adjust headlamps

4.1 h

32 960 01

Mercedes-Benz
Global Service & Parts

Field measure management GSP/TPR

P-SC-2020040021

https://www.startekinfo.com/StarTek/outside/224223/?requestedDocId=224223

Taking too long?

Reload document

Open in new tab

Download [46.25 KB]
