WORK DESCRIPTION FOR FIELD MEASURE
Code: 23P5490210
Version: 2.0
Apply preservation agent to PTC Heater Electrical Connections
Model 243
Work procedure
The following points must be observed prior to carrying out the work.
- Ignition OFF
- No accident vehicle
- The charging cable must be disconnected on the vehicle side
- Hood open
- A visual check of the electric lines in the high-voltage on-board electrical system for loose contacts or damaged insulation must be carried out in the working area.
It is not necessary to disconnect the power to carry out the work.
- Remove lower engine compartment lining (AR61.20-P-1105EQA).
- Apply a generous amount of spray wax to the ground line (A, Figure 1) on the high-voltage PTC heater so it coats all sides and surfaces of the connector.
After applying the first layer of wax, let it air-dry for 10 minutes and then repeat the waxing process a second time.
Make sure that the stranded copper wires in the ground strap (B, Figure 2) are fully covered with wax.
- Apply a generous amount of spray wax to the retaining clamp (C, Figure 3) of the electric lines on the high-voltage PTC heater.
Position the spray probe of the wax can upstream of the groove (D, Figure 4) to ensure that the wax goes under the retaining clamp.
After applying the first layer of wax, let it air-dry for 10 minutes and then repeat the waxing process a second time.
- Install lower engine compartment lining (AR61.20-P-1105EQA).
Parts
| Quantity | Designation | Part no. |
| As required (1*) |
Wax | A 000 986 32 01 09 |
* One container of wax is sufficient for at least 10 vehicles.
PTC Heater Electrical Connection Preservation Agent
Model(s) EQB300W4,EQB350W4
Model Year 2022-2022
https://www.startekinfo.com/service/download-document/outside/228253/
https://static.oemdtc.com/TSB/P-SC-2023090007.pdf
