Campaign No. 2020120010 January, 2021
| TO: | ALL MERCEDES-BENZ CENTERS |
| SUBJECT: | Model 907 Model Year 2020 Replace Transfer case |
MBAG, the manufacturer of Mercedes-Benz Sprinter Vans, has determined that the has determined centering of the transmission plate may not have been carried out correctly during the assembly of the transfer case in certain vehicles with all-wheel drive. This would become noticeable through noises in the vehicle interior and result in the gearshift system for the reduction not functioning correctly.
Prior to performing this Service Campaign:
- Please check VMI to determine if the vehicle is involved in the Campaign and if it has been previously repaired.
- Please review the entire Service Campaign bulletin and follow the repair procedure exactly as described.
Approximately 12 vehicles are affected.
Order No. V-SC-2020120010
Replace Transfer Case
Model 907
Model Year 2020
https://www.startekinfo.com/service/download-document/outside/225002/
https://static.oemdtc.com/Recall/V-SC-2020120010.pdf
Loading...
Reload document
Open in new tab
- ATF 134 Mercedes Benz Transmission Fluid
- Perfect choice for maintaining the performance and longevity of your Mercedes Benz vehicle
- Engineered with precision and care
- With advanced formulation and exceptional performance characteristics
- Ensures smooth shifting, reliable power delivery, and optimal protection against wear and friction
- Pentosin ATF 134 FE was developed to further optimize gearbox efficiency of latest generation Mercedes-Benz 7G Tronic Plus automatic transmissions
- Fluid meets Mercedes spec. 236.15 and is OE approved for Mercedes Benz 7-speed transmissions produced after June 2010 (MB OE # 001-989-78-03)
- Lowest viscosity ATF available provides impressive fuel economy potential and low-temperature behavior
- Blue in color - not backwards compatible with earlier red Mercedes spec fluids used in prior 7-speed automatic transmissions; 5 liter jug - sold individually
- For select vehicles: Mercedes-Benz: 2010-15 C250, 2010-16 C300, 2010-15 C350, 2015 C400, 2016 C450 AMG, 2010-20 C63 AMG, 2015-20 C63 AMG S, 2010-14 CL550, 2010-14 CL63 AMG, 2015-16 CLS400, 2010-16 CLS550, 2010-14 CLS63 AMG, 2014-18 CLS63 AMG S
- Shell ATF 134 Mercedes Benz Transmission Fluid 236.14 236.12
- premium semi-synthetic automatic transmission fluid designed for use in Mercedes Benz 7 speed transmission
- Meets MB approval 236.14
- This product replaces all ATF products listed on MB approval 236.12
- Shell ATF 134 is approved for use for the latest NAG2V sport transmission with west starting clutch (model 0722.930, 931, 932) and the 7G-Tronic (models 722.9 / W7A 700 /NAG2)
- Pentosin ATF 134 is an ultra high-performance automatic transmission fluid developed to improve shifting comfort for Mercedes-Benz vehicles equipped with 5-Speed 722.6 & 7-Speed 722.9 automatic transmissions
- ATF 134 offers excellent low temperature properties, outstanding fuel-efficiency potential, and increased friction stability; Red in color - not compatible with later blue Mercedes spec fluids used in newer 7-speed automatic transmissions
- Backward compatible to products fulfilling the requirements of MB-Approval 236.12, but a full fluid change is recommended to take best advantage of all ATF 134 qualities
- Product Attributes: Red Color, 0.848 g/ml Density at 15°C, Flash Point>206°C/>402°F, 29.6 mm²/s Kinematic Viscosity at 40°C, 185 Viscosity Index
- OE Reference Numbers: Mercedes-Benz: 001989680313, 001989680310; Approvals/Specifications: Mercedes-Benz 236.14; 5 liter jug; Sold individually
- Fitment Notes: Fitment Notes
With 722.9xx 7-Speed Automatic Transmission and Without Code A89 - Direct fit replacement
- Installs the same as factory unit
- Same dimensions as Original Part
- REPLACEMENT AUTOMATIC TRANSMISSION FILTER KIT : The inline automatic transmission filter keeps contaminants out of the transmission fluid. There are a number of problems that can arise with the filter, which reduce its ability to do its job properly. Symptoms of a bad transmission filter are unusual noise, leakage, contamination, inability to change gears, smoking, please take a minute to check the transmission filter.
- COMPATIBLE WITH MERCEDES BENZ 722.9 W219 W221 VEHICLES : 2006-2009 C230 | 2010-2015 C250 | 2008-2014 C300 | 2006-2015 C350 | 2008-2018 C63 AMG | 2004-2006 CL500 | 2007-2014 CL550 | 2008-2014 CL63 AMG | 2006-2009 CLK350 | 2005-2006 CLK500 | 2007-2009 CLK550, CLK63 AMG | 2007-2016 CLS550 | 2007-2013 CLS63 AMG | 2014-2016 E250 | 2012-2016 E300 | 2004-2005, 2007-2009 E320 | 2006-2016 E350 | 2004-2006 E500 | 2007-2017 E550 | 2007-2013, 2015 E63 AMG | 2009-2012 G550 Automatic Transmission Filter Kit.
- COMPATIBLE WITH MERCEDES BENZ 722.9 W219 W221 VEHICLES : 2007-2009 GL320 | 2010-2016 GL350 | 2007-2016 GL450 | 2008-2016 GL550 | 2013-2015 GLK250 | 2010-2015 GLK350 | 2007-2009 ML320 | 2006-2015 ML350 | 2006-2007 ML500 | 2008-2015 ML550 | 2006-2013 R350 | 2012-2013 S350 | 2010-2013 S400 | 2008-2011 S450 | 2007-2016 S550 | 2007-2016 SL550 | 2009-2018 SL63 AMG | 2013-2018 SL65 AMG | 2012-2015 SLK250 | 2009-2011 SLK300 | 2005-2016 SLK350 | 2005-2016 SLK55 AMG Automatic Transmission Filter Kit.
- OE FIT, FORM, FUNCTION : Professional, high quality OE style and meet or exceed all original equipment performance replacement automatic transmission filter kit. Brand New and ready to install straight out of the box. Made with high quality materials, high quality construction for durability and designed is to keep your transmission ( transmission fluid ) clean.
- FRIENDLY NOTE : If the Automatic Transmission Filter Kit fails on your vehicle, simply contact us for a replacement. Also if you have any other questions on our this Automatic Transmission Filter Kit, please contact us at the first time. This is NOT a genuine part, it's a aftermarket replacement part manufactured by Allmotorparts.
- 【EASY TO USE: HOT and COLD】 markings let you check your fluid level easily without the need for remembering numbers and measurements.
- 【INSTRUCTIONS INCLUDED】 so you can accurately mantain and monitor fluid level without going to the Dealership.
- 【INCLUDES NEW TRANSMISSION CAP LOCKING PIN】INCLUDES NEW TRANSMISSION CAP LOCKING PIN which will need to be replaced to "re-seal" the transmission.
- 【 VEHICLE TOOL PART # 】Reference Part Numbers: 140589152100 / 1409910055
- 【DEALER Style MULTI VEHICLE TOOL】 : Not to be left in vehicle! Refit sealing cap after fluid level check.
- FOR USE IN 95% of ATF VEHICLES INCLUDING MOST CVTs in operation with US registered light duty applications
- HIGH PERFORMANCE CONDITIONING AGENTS prolong seal elasticity to prevent leaks
- IMPROVE DURABILITY & TRANSMISSION LIFE with anti-wear technology to avoid costly repairs
- ENHANCED HIGH & LOW TEMP PERFORMANCE supports transmission fluid in all weather situations
- FULL SYNTHETIC FORMULA protects against engine breakdown better than conventional fluids
Last update on 2024-07-25 / Affiliate links / Images from Amazon Product Advertising API
This product presentation was made with AAWP plugin.
SEOCONTENT-START
This bulletin has been created and maintained in accordance with MBUSA-SLP S423QH001, Document and Data Control, and MBUSA-SLP S424HH001, Control of Quality Records. Model 907 with code AR2 (Axle ratio i = 3,923) with code ZG3 (Engageable all-wheel drive with gear reduction) Model 907 with code AR3 (Axle ratio i = 4,182) with code ZG3 (Engageable all-wheel drive with gear reduction) Operation no. of the operation texts or standard texts and flat rates Category Op. no. Operation text Time Acc. no. Code L 02 1095 Operations: Replace transfer case 2.0hrs 28 900 67 VS3PASSB OL L 02 3282 Operations: Remove underfloor paneling (when working on veh.) 0.2hrs 28 900 67 VS3PASSB OL D28.10-A000-09 1 Transfer case 3 Electrical connector 6 Electrical connector 2 Vent line aDanger Risk of death caused by vehicle slipping or toppling off of the lifting platform. Align vehicle between vehicle lift columns and position the four support plates at the vehicle lift support points specified by the vehicle manufacturer. AS00.00-Z-0010-01A V-SC-2020120010 1 g Check 1 Check if vehicle is affected by measure. Affected vehicles: Replace transfer case (code: VS3PASSBOL, acc. no.: 28 900 67) Model 907.### #P from 283008 to 292195 SM28.10-D-0008-01AAA i For authorized Mercedes‑Benz service partners, only the entry in the Extended VEGA Application (EVA) system, in the “Current” tab, is decisive. An additional test of the affected vehicles in the workshop information system (WIS) or vehicle list is thereby not necessary. Replace transfer case (1) 2 Raise vehicle. Topical note Special instructions for lifting and supporting vehicle AH00.60-N-0100-01TS f AR00.60-D-1000-04TS 3 Remove underbody paneling. f Model 907 with code XM1 (Noise abatement measures) AR61.30-D-1001TS 4 Remove propeller shaft from front axle differential. f AR41.10-D-0070TSX 5 Detach propeller shaft from transfer case (1). f AR41.10-D-0050TS i Removal: To do so, counterhold propeller shaft, remove screws and detach propeller shaft from output flange of transfer case (1). i Aid of helper required. n Screw, propeller shaft to output flange of transmission/ transfer case BA41.10-N-1001-01TS 6 Disconnect electrical connectors (3, 6). 7 Pull bleed line (2) out of crossmember (arrow). i Do not kink bleed line (2). 8 Support transfer case (1) using major assembly support and mounting plate and secure with tensioning strap. A 000 588 11 62 00 Major assembly mount WS01.00-P-0092B A 000 588 10 62 00 Support plate WS26.00-P-3309B 2 V-SC-2020120010 9 Remove transfer case (1). i Installation: Grease drive shaft gearing. i To do so, remove screws of transfer case (1) from connecting flange to transmission. n Screw, transfer case to connecting flange BA28.10-N-1002-01TSR Anticorrosion grease 40 g / DB supply specification 6834.00 BR00.45-Z-1006-06A 10 Install in the reverse sequence. g Check 11 Check oil level in transfer case (1). f AR28.10-D-1000-26TSX g Automatic transmission fluids (ATF) (specification 236.12) BB00.40-P-0236-12A n Drain screw to transmission housing BA28.40-N-1001-01E n Filling screw to transmission housing BA28.40-N-1002-01E If oil level is not OK: ↓ Correct oil level. d Install 12 Install underbody paneling. f Model 907 with code XM1 (Noise abatement measures) AR61.30-D-1001TS 13 Lower vehicle. n Complete transfer case Number Designation Model 907 with code ZG1 (Engageable all-wheel drive) Model 907 with code ZG3 (Engageable all-wheel drive with gear reduction) BA28.10-N-1002-01TSR Screw, transfer case to connecting flange Nm 28 V-SC-2020120010 3 n Transfer case housing Number Designation Model 907 with code ZG1 (Engageable all-wheel drive) or with code ZG3 (Engageable all-wheel drive with gear reduction) BA28.40-N-1001-01E Drain screw to transmission housing Nm 40 n Transfer case housing Number Designation Model 907 with code ZG1 (Engageable all-wheel drive) or with code ZG3 (Engageable all-wheel drive with gear reduction) BA28.40-N-1002-01E Filling screw to transmission housing Nm 40 n Propeller shaft Number Designation Model 907 except code G42 BA41.10-N-1001-01TS Screw, propeller shaft to output flange of transmission/ transfer case M10x1 Stage 1 Nm 40 Stage 2 ∡° 60 M12x1.5 Stage 1 Nm 40 Stage 2 ∡° 60 Repair materials Number Designation Order number BR00.45-Z-1006-06A Anticorrosion grease 40 g / DB supply specification 6834.00 A 001 989 37 51 10 4 V-SC-2020120010 Parts ordering note Part no. Designation Quantity A 907 280 05 00 Transfer case (with code AR2 (Final drive ratio i = 3.923)) n. B. A 907 280 06 00 Transfer case (with code AR3 (Final drive ratio i = 4.182)) n. B. V-SC-2020120010 5
**************************************************************************************************************
