April 6, 2023
2023030004
Check Convertible Roof Frame, Calibrate if Necessary
This is to notify you of the Service Campaign Launch to check the convertible roof frame outlet flap on 153 Model Year (“MY”) 2022-2023 SL (232 platform) vehicles. The vehicles will be visible and flagged in VMI as “OPEN” on April 6, 2023.
Issue
Mercedes-Benz AG (“MBAG”), the manufacturer of Mercedes-Benz, has determined that on certain MY 2022-2023 SL (232 platform) vehicles, the software of the rear control unit may not meet current production specifications. Therefore, the possibility exists that the soft top may not close from the “soft top open” position.
What We’re Doing
MBUSA will conduct a service campaign. An authorized Mercedes-Benz dealer will check and calibrate the roof frame outlet flap, if necessary.
Parts
The remedy is available and can be performed as necessary.
Calibrate convertible roof frame outlet flap (GAK) at soft top
- Always use the latest XENTRY Diagnosis software release with all available add-ons.
- Make sure to follow the operation steps exactly as described in XENTRY Diagnosis.
- Use a charger to ensure sufficient power supply to the vehicle’s on-board electrical system battery (greater than 12.5 V).
- If XENTRY Diagnosis is already connected to the vehicle, start with Work Procedure step 2.
If two or more software updates or SCN codings are performed during a single workshop visit, the operation items 02-4762 and 02-5058 may only be invoiced only on one of the workshop orders.
Work Procedure
GAK is the German abbreviation for Header Bow
- Connect XENTRY Diagnosis.
- Update rear control unit (SG-FOND) software.
To do this, select menu item “Quick test view – N22/6 rear control unit (SG-FOND)-Adaptations – Control unit update – Updating of control unit software”.
Then follow the user guidance in XENTRY Diagnosis.
If no new software is found, the latest version is already installed. In this case, continue to follow the work instructions.
XENTRY Diagnosis will fully guide you through the following operations.
(The figures below are examples only and serve to provide a better understanding of the operations to be carried out).
Check/test procedure
- Identify the work procedure (left GAK and/or right GAK) with XENTRY Diagnosis.
- Read out calibration data (ACTUAL values) with XENTRY Diagnosis.
To do this, select menu item “Quick test view – N22/6 control unit – Rear control unit – Control unit log => Read out ACTUAL values.
- Save calibration data as a PDF, open and identify defective convertible roof frame outlet flap (GAK) (figure 1) and determine the required rework scope (figure 2)
Example: -8 not OK. Here the left GAK must be moved to the rear.
- Move soft top into convertible position and Header Bow (GAK) into intermediate position (figure 3). For this purpose, move to position via the soft top switch (1).
- Open soft top locks via XENTRY Diagnosis (figure 4).
Important note: Risk of damage!
The electric motor is actuated without monitoring. Once the position is reached, the button must be released. Risk of damage!
2 people are required for the performance of this operation!
Person 1: Visual height adjustment (soft top (A) and GAK rear edge (B)) Person 2: Gradual raising of soft top via Xentry
- Raise soft top (A) to same height as GAK rear edge (B) (figure 5).
For this purpose, gradually raise soft top (A) via Xentry (figure 6).
To determine the lowest clearance, soft top (A) and GAK rear edge (B) must be at the same height.
The following distance measurements must always be carried out with a raised soft top coming from the convertible position (most critical distance in the movement) Risk of damage to soft top!
Only perform the operation step if the values of the convertible roof frame outlet flap (GAK) are not OK!
- Readjustment of not OK GAK (figure 7)
- Gradually move back convertible roof frame outlet flap (GAK) via XENTRY to a distance of 17 mm (figure 8).
Check whether sensors for GAK 1 intermediate position are at “Actuated”.
Note: Per actuation, the mechanical system is moved backwards by approx. 1-2 mm
2 people are required for the performance of this operation!!
Person 1: Measurement of distance
Person 2: Movement of GAK via Xentry
- Manually raise soft top via Xentry up to “Cobra position” (figure 10).
The value must lie between 800 and 900 on the right side and -800 and -900 on the left side. Both values of “Hall Sensor Motor CT left/right” show this value (see figure 11).
- Start teach-in run of soft top via XENTRY (figure 12).
- If the teach-in process is not successful (figure 14), please create a TIPS case. If the teach-in process was successful, continue with operation step 12.
- Read out calibration data and export as a PDF (figure 15).
- Evaluate calibration data.
In the case of not OK data after the calibration, please create a TIPS case.
Check Convertible Roof Frame Outlet Flap
Model(s) SL43R,SL55R4,SL63R4
Model Year 2022-2023
https://www.startekinfo.com/service/download-document/outside/227674/
https://static.oemdtc.com/Recall/P-SC-2023030004.pdf
