WORK DESCRIPTION FOR FIELD MEASURE
Code: 21P8298702
Version: 2.0
Update map data of NTG7 head unit
Model 223 with code 534
Work procedure
1. Go to the start screen and open the settings in the head unit.
2. Tap on “Assistance” 8 to 10 times.
3. Go to the “Navigation” tab and select the “delete mapdata” submenu.
4. Update map data for navigation system.
For basic data, see AR82.85-P-0100LWG.
The field “Request activation code” (A, Figure 3) must be active, otherwise the necessary authorizations are missing.
Operation text and flat rate
| Operation | Operation text no. | Flat rate | Accounting no./ damage code |
| 02-0921 | Update map data of head unit Includes:
Connect/disconnect starter battery charger |
0.5 h | 82 987 02 |
Mercedes-Benz
Global Service & Parts
Field measure management GSP/TPR
Update map data of NTG7 head unit
Model S-Class (223 Platform)
Model Year 2021
https://www.startekinfo.com/service/download-document/outside/225597/
https://static.oemdtc.com/TSB/P-SC-2021080001.pdf
